C-band amplifier (EDFA, 1U Rack Mount)

A 19-inch 1U rack-mount C-band EDFA for long-haul terrestrial and metro WDM transmission, split into booster/in-line and pre-amplifier lines.

Technical overview

The AMP-FL5011-CB line is the booster/in-line variant (>= +19 or +22 dBm output, >= 35 dB gain, NF <= 6 dB) and the AMP-FL5013-CB line is the pre-amplifier/in-line variant (>= +13 to +19 dBm output, >= 25 to 30 dB gain, NF <= 5 dB). Both cover 1530 to 1560 nm at 1550 nm nominal, with the header quoting 1530 to 1565 nm. The 43 x 440 x 403 mm chassis has redundant hot-swap AC power, SC/PC connectors, RS-232C plus an alarm relay, and carries IEC 60825-1 and CE marking.

Conditioning Routing

Features

Proven in Various Deployment Conditions (from R&D to Actual Network)
Monitoring/Logging/Interlocking Function
RS-232C
SNMP Option

Specifications

Specifications
Parameter	Value
Product numbers	AMP-FL5011-CB-19 / -22; AMP-FL5013-CB-13 / -16 / -19
Operating wavelength (spec table)	1530 to 1560 nm
Operating wavelength (product header)	1530 to 1565 nm
Nominal wavelength	1550 nm
Output power (input 0 dBm at nominal wavelength)	>= +13 / >= +16 / >= +19 / >= +22 by grade dBm
Gain (input -30 dBm at nominal wavelength)	>= 35 (5011-CB) / >= 25 (5013-CB-13) / >= 30 (5013-CB-16, -19) dB
Noise figure (input -30 dBm at nominal wavelength)	<= 6 (5011-CB) / <= 5 (5013-CB) dB
Input/output fiber	SMF, G.652 compliant (e.g. SMF28)
Standard connector	SC/PC
Input/output isolator	Built In
Standard dimensions (H x W x D)	43 x 440 x 403 mm
Safety function	Interlock with input level Alarm
Control mode	ACC (Auto Current Control) and ALC (Auto Light Control)
Remote interface	RS-232C / Relay terminal for alarm
Operating temperature	0 to 40 degC
Storage temperature	-10 to 60 degC
Power supply	AC 100 to 240 V (50/60 Hz), Redundant and Hot-Swap
Humidity	5 to 80 % RH (non-condensing)
Safety standards	IEC 60825-1 (JIS C 6802) / CE marking (EN 61010-1 / EN 61326-1)
